FusionNOS
Advanced Deep Packet Processing System
for Packet Broker

Name: FusionNOS
SKU: FusionNOS

Asterfusion‘s Linux-based NOS built for DPU platforms. It delivers advanced network packet broker functions and acceleration for backend analytics. Powered by DPDK, it achieves high-performance packet processing on ARM/x86 systems.

What’s in FusionNOS

Cost and Architecture

Based on general-purpose ARM/x86 platforms with DPDK-accelerated high-performance traffic processing, eliminates reliance on specialized hardware and significantly reduces deployment costs.

Modular Design

Based on an NFV architecture, different traffic processing functions are packaged as VNF software modules, allowing flexible combination and deployment according to the required services, with elastic scaling.

Deep Packet Processing

Supports fine-grained packet preprocessing operations, including packet deduplication with order preservation, IP fragmentation reassembly, TCP reordering, and data masking.

REST & Multi-Env Deployment

Open Management

Provides open REST APIs for third-party integration and service orchestration. Supports Web UI, SNMP, and CLI management for flexible adaptation.

Flexible Deployment

Supports physical deployment (ARM/x86), virtualized deployment (VMware, KVM, etc.), and cloud deployment (OpenStack, with plans to extend to mainstream public clouds).

Deployment in Asterfusion

SKU with DPU Card

Available on the Asterfusion CX306P-48Y-M-H switch, the optional DPU Card(CN103/CN9670) allows FusionNOS to be deployed on it—enabling NetFlow/IPFIX export, NPB functionality, VLAN processing or other switch-level operations.

Asterfusion Helium SmartNIC

Running FusionNOS on Helium EC2002P SmartNIC and EC2004Y SmartNIC provides a foundation for developing user-defined upper-layer applications, enabling network, security, and storage acceleration.

DPU Network Platform

ET3212A and ET3424A are preloaded with FusionNOS, providing a foundation for developing upper-layer applications. They support virtual network function offloading, network visibility, and backed tools acceleration.

Specifications based on 32GB RAM

Functional Features	Level 1 Function	Level 2 Function
Advanced Features	Flow Filtration	Support for IPv4/IPv6 wildcard seven-tuple rules
Advanced Features	Flow Filtration	Supports L2 source-destination mac, Ethernet protocol type rules
Advanced Features	Flow Filtration	Supports IPv4/IPv6 exact quintuple rules
Advanced Features	Flow Filtration	Support fixed window keyword rules/floating window keyword rules
Advanced Features	Flow Filtration	Support for URL rules
Advanced Features	Flow Filtration	Support TCP Flag rules, including "fin", "syn", "rst", "psh", "ack", "urg", "ecn", "cwr", "nonce".
Advanced Features	Flow Filtration	Support for combination rules
Advanced Features	Load Balancing	Supports the creation of logical outgoing interfaces (ELAG)
Advanced Features	VLAN Processing	Supports adding VLANs, removing outer VLANs, and modifying VLANs
Advanced Features	Message Processing	TCP Reorganization
Advanced Features	Tunnelling	Supports GRE, VXLAN, ERSPAN tunnel encapsulation stripping
Advanced Features	Tunnelling	Supports stripping one or more layers of VLAN encapsulation
Advanced Features	Tunnelling	Supports stripping one or more layers of MPLS encapsulation
Advanced Features	Flow Filtration	Support vlan, mpls, gre, vxlan, ssl_tls, ipip, ip6, ip6ip, ip6ip6, teredo, ipsec_ah, ipsec_esp, ftp, pop3, smtp, dns, radius, coap, pptp, l2tp, https, icmp bgp, ospf, isis, gtp, sctp message type filtering
Advanced Features	Traffic Forwarding	Supports forwarding to a specific port or group of ports
Advanced Features	Traffic Replication	Supports replication to a port or ELAG group
Advanced Features	Convergence	Supports multiple traffic aggregation
Advanced Features	Load Balancing	Supports load balancing policies based on source-destination IP, quintuple, and tunnel inner IP quintuple;
Advanced Features	Load Balancing	Supports static, dynamic, and load balancing modes with weights
Advanced Features	Load Balancing	Support capture message same source and same host output
Advanced Features	Message Processing	Supports message de-duplication, optionally ignoring TTL, MAC, L2, DSCP, interface (cpu interface), TCP (including seq_num and ack_num for tcp, checksum for tcp), IPID, FCS, and optionally supporting (sport, dport, sip, dip, smac, dmac) fields.
Advanced Features	Message Processing	Support for timestamping
Advanced Features	Message Processing	Support for Message Specified Offset Stripping
Advanced Features	Message Processing	Supports outer layer MAC address modification
Advanced Features	Message Processing	Supports message truncation
Advanced Features	Message Processing	Supports message desensitization
Advanced Features	Message Processing	Supports IP slice reorganization
Advanced Features	Message Encapsulation	Supports GRE, VXLAN, ERSPAN I, ERSPAN II, ERSPAN III, TCP encapsulation
Advanced Features	End of Tunnel	Supports GRE, VXLAN tunnel termination
Advanced Features	Message Output	Supports message sampling output; supports NetFlow and sFlow
Advanced Features	Ports	Support port multiplexing; support automatic monitoring of port link status and security protection
Advanced Features	Basic Management Features	Support serial port, SSH, RestAPI, CLI management methods
Advanced Features	Basic Management Features	Supports online security upgrades
Advanced Features	Basic Management Features	Support configuration file import and export
Advanced Features	Basic Management Features	Supports NTP clock synchronization
Advanced Features	Basic Management Features	Supports SYSLOG log management
Advanced Features	Basic Management Features	Supports LLDP sending
Advanced Features	Basic Management Features	SNMP support
Advanced Features	Statistical Properties	Support device status statistics, including system memory and CPU usage
Advanced Features	Statistical Properties	Supports interface information statistics, including interface configuration and status, interface packet type statistics, interface packet count and rate statistics.
Advanced Features	Statistical Properties	Supports rule hit statistics, reorganization function statistics, de-duplication function statistics, NetFlow statistics
Basic Management Features	Support serial port, SSH, Telnet, CLI management methods	-
Basic Management Features	Supports online security upgrades	-
Basic Management Features	Configuration Management	Support configuration file import and export, configuration saving
Basic Management Features	Configuration Management	Configure management network port IP, gateway
Basic Management Features	Configuration Management	Supports clearing configurations by service type, and can clear forwarding policies or interface configurations individually
Basic Management Features	Supports NTP clock synchronization	-
Basic Management Features	Supports SYSLOG log management	Support for modifying the protocol port number (default 514), support for specifying the syslog server
Basic Management Features	Supports LLDP send and receive	-
Basic Management Features	Support FTP,TFTP	-
Basic Management Features	Condition Monitoring	Support to view temperature, fan information
Basic Management Features	Condition Monitoring	Support for viewing power supply information
Basic Management Features	Condition Monitoring	View current version information
Basic Management Features	Condition Monitoring	Show Current Configuration
Basic Management Features	Condition Monitoring	Display system time
Basic Management Features	Condition Monitoring	Displaying Management Port Information
Basic Management Features	Condition Monitoring	Display CPU/Memory usage status
Basic Management Features	Condition Monitoring	Device alarms, support temperature alarms, power out of position alarms, fan out of position alarms, traffic overflow alarms
Basic Management Features	Performance Monitoring	Port Traffic Threshold Settings
Basic Management Features	Support for user management	Creating/Deleting new users
Basic Management Features	Support for user management	User Lock/Unlock
Basic Management Features	Support for user management	Support password change
Basic Management Features	Support for user management	Display user information
Basic Management Features	Support for TACACS+	Support device management user login authorization
Basic Management Features	Support for TACACS+	Support for Master and Standby Authentication Servers
Basic Management Features	SNMP support	Support mib download, SNMP agent, SNMP Trap, support SNMP v1, v2c, v3
Basic Forwarding	L2/L2V6 rule filtering	Destination MAC
Basic Forwarding	L2/L2V6 rule filtering	Source MAC
Basic Forwarding	L2/L2V6 rule filtering	Outer VLAN
Basic Forwarding	L2/L2V6 rule filtering	IP Version
Basic Forwarding	L2/L2V6 rule filtering	Any combination of the above fields
Basic Forwarding	L3/L3V6 rule filtering	IP Version
Basic Forwarding	L3/L3V6 rule filtering	Outer VLAN
Basic Forwarding	L3/L3V6 rule filtering	Source / Destination IP Support Mask
Basic Forwarding	L3/L3V6 rule filtering	Source / Destination Port
Basic Forwarding	L3/L3V6 rule filtering	IP Protocol
Basic Forwarding	L3/L3V6 rule filtering	VLAN Priority
Basic Forwarding	L3/L3V6 rule filtering	Source MAC
Basic Forwarding	L3/L3V6 rule filtering	Any combination of the above fields
Basic Forwarding	Mirrored mode tributary interfaces hold configurations in the inbound or outbound direction.	Incoming Direction Configuration
Basic Forwarding	Mirrored mode tributary interfaces hold configurations in the inbound or outbound direction.	Outward Direction Configuration
Basic Forwarding	Forwarding mode supports configuration in the RX direction of the incoming interface	-
Basic Forwarding	Support for viewing and clearing policy-based hit statistics	-
Basic Forwarding	Support for viewing and clearing ACL hit statistics	-
Basic Forwarding	IP messages flowing through the input port to the output port are guaranteed to be complete, with no changes in number, format, or content, including TTL bits	-
Basic Forwarding	Rule Search	-
Connector	Interface Rate Configuration	-
Connector	Support Interface Enable Disable Interface	-
Connector	Supports FEC configuration	-
Connector	Supports MTU configuration	-
Connector	Supports delayed startup of interfaces	-
Connector	Support network configuration, such as IP, MAC	-
Connector	Support for interface statistics	Packet & Byte Count
Connector	Support for interface statistics	Error packet statistics
Connector	Support for interface statistics	Packet Loss Statistics
Connector	Support for interface statistics	Rate statistics
Connector	Support for interface statistics	v4 or v6 packet counts
Connector	Traffic Statistics Export	Statistics including packet count, byte count, rate, etc.
Connector	Port Buffer	Based on global shared cache and port-independent cache, not configurable
Connector	Module Information Acquisition	incumbency information
Connector	Module Information Acquisition	Manufacturer Information
Connector	Module Information Acquisition	Optical Power Information
Connector	Module Information Acquisition	Relevant threshold information
Connector	Port Mode	Support rx&tx mode
Connector	Port Mode	Port Loopback Support
Connector	Port Mode	port transceiver multiplexing
Connector	Port Mode	Support span/rspan/forward mode switching
Connector	Port Batch Configuration	Supports port bulk configuration
Convergence	Supports multiple traffic aggregation to a single port	-
Convergence	Supports multiple traffic aggregation to a single lag	-
Traffic Replication	Supports replication to one or more ports based on forwarding policy	-
Traffic Replication	Supports replication to multiple ports and LAG groups or multiple LAG groups based on forwarding policy	-
Tunneling	GRE Tunnel Ends	-
Tunneling	VXLAN tunnel termination	-
Tunneling	Supports stripping of IPGRE/NVGRE headers and GRE headers containing optional fields	-
Tunneling	Supports stripping of VXLAN headers	-
VLAN processing	Add a layer of vlan after port-based mirroring	-
VLAN processing	ACL-based addition of an outermost layer to the vlan	-
VLAN processing	Modify the outermost layer of the vlan based on ACLs	-
VLAN processing	Deletion of the outermost layer based on ACLs for vlan	-
Port Mirroring	Input port based mirroring, supports selection of mirroring direction (RX or TX or both), can support multiple different input ports mirrored to one output port	-
Packet Truncation	Supports message truncation in mirror mode, fixed truncation of 128 bytes	-
Load Balancing	Manual Mode	Supports up to 128 lag groups, each group supports up to 8 members
Load Balancing	Load Balancing Mode	Supports elastic load balancing, when a port is down, only the traffic from the downed port is reloaded to other members of the lag
Load Balancing	Fixed load balancing members	As long as the lag members are the same, the load balancing result is the same
Load Balancing	Supports hash mode global and inbound port based tuning	src-dst-ip
Load Balancing	Supports hash mode global and inbound port based tuning	src-dst-ip-port
Load Balancing	Supports hash mode global and inbound port based tuning	src-dst-mac
Load Balancing	Supports hash mode global and inbound port based tuning	src-dst-mac-ip
Load Balancing	Supports hash mode global and inbound port based tuning	src-dst-mac-ip-port
Load Balancing	Support for customized hash patterns	Supports up to 16 different key combinations, supports any key combination of IP/MAC/port numbers
Load Balancing	Support for hash seed adjustment	-
