CX732Q-M-H

32x400Gb QSFP-DD, L3 Aggregation/Spine Switch,  Enterprise SONiC NOS, MLAG VXLAN Support

Please login to request a quote
CX732Q-M-H-layer3-aggregation-switch-1
CX732Q-M-H-layer3-aggregation-switch-2
CX732Q-M-H-layer3-aggregation-switch-3
CX732Q-M-H-layer3-aggregation-switch-4

32-port 400 GbE QSFP-DD L3 Aggregation Switch, Enterprise SONiC Ready, Marvell Falcon

The Asterfusion CX732Q-M-H is a 32 x 400G QSFP-DD spine switch designed for enterprise aggregation spine applications. The 400G open network switch based on the Marvell Falcon chip offers L2/L3 up to 12.8 Tbps switching capacity performance. Benefiting from commercial SONiC NOS-AsterNOS, it supports rich layer 2 and layer 3 functions, including routing functions like OSPF and BGP, and other features like MLAG and IPV6 functions. With a compact 1RU form factor. This 400G aggregation switch offers a perfect solution for campus networks, SMBs, and enterprise networks.

Specifications

Ports32x 400G QSFP-DD
2x 10G SFP+		Switch ChipMarvell Falcon
Switching Capacity3.2 TbpsMAC Address Entries24K
Forwarding Rate2.8 BppsIPv4 Prefix Routes504K
SDRAMDDR4 16 GBIPv6 Prefix Routes252K
SSD Memory128 GBPacket Buffer24 MB
Hot-pluggable AC Power Supplies2 (1+1 Redundancy)Hot-pluggable Fans6 (5+1 Redundancy)
Dimensions (HxWxD)44x 440x 515mmMax. Power Consumption<970W
Weight12KGRack Units1 RU
Operating Temperature0 - 45℃Thermal AirflowFront-to-Rear

Hardware Panel

aggregation-switch-panel_CX732Q-M-H

Software

Features

layer-2-features-icon

Layer 2 Features

  • 4K VLANs
  • Voice VLAN
  • Multiple Spanning Tree Protocol
  • QinQ
  • Link Aggregation Control Protocol
  • Multi-Chassis Link Aggregation
  • VLAN Trunking
  • Link Layer Discovery Protocol (LLDP)
  • LLDP Enhancements for PoE
  • Port Isolation
  • Jumbo Frames (9216 Bytes)
  • IGMP Snooping
  • Storm Control
  • Monitor Link
  • BPDU Guard, BPDU Filter
  • Loopback Detection
layer-3-features-icon

Layer 3 Features

  • IPv4/v6 Dual Stack
  • Policy Based Routing
  • Resilient ECMP
  • ARP-to-Host
  • VRF
  • Bi-Directional Forwarding Detection (BFD)
  • IGMP v2/v3
  • Route Map
  • VRRP
  • GRE
  • Routing Protocols: OSPF v2/v3, BGP, MP-BGP
security-features-icon

Security Features

  • Service ACLs
  • ACL Logging and Counters
  • Control Plane Policing (CoPP)
  • Dynamic ARP Inspection (DAI)
  • IP Source Guard v4/v6
  • DHCPv4/v6 Relay
  • DHCPv4/v6 Snooping
  • ND Snooping
  • 802.1x Authentication
  • Portal Authentication
  • MAC Authentication Bypass (MAB)
  • Dynamic VLAN Assignment
  • TACACS+
  • RADIUS
  • IPSG/DAI/SAVI
management-and-monitoring-icon

Management and Monitoring

  • Asteria Campus Controller
  • Industry Standard CLI
  • Zero Touch Provisioning (ZTP)
  • SNMP v1/v2/v3
  • sFlow
  • Port Mirroring
  • Syslog
  • Log Management
  • PTP IEEE 1588v2 (TC and BC)
  • Containerized Custom Tools
  • BGP/BFD Operational Status
quality-of-service-icon

Quality of Service (QoS)

  • 8 Queues per Port
  • 802.1p Based Classification
  • DSCP Based Classification
  • Strict priority queueing
  • DWRR Scheduling
  • Policing/Shaping
  • Rate Limiting
virtualization-features-icon

Virtualization Features

  • VXLAN Centralized/Distributed Gateway
  • EVPN Type 2/3/5

32-Port 400GbE QSFP-DD Aggregation Switches with PTP Support (Optional)

The CX732Q-M-H aggregation switches fully support IEEE1588 PTPv2 and SMPTE 2059-2 standards through hardware and software. The hardware port supports PTP as a Boundary Clock (BC) or Transparent Clock (TC), with customizable modules to fit customer needs. On the software side, Asterfusion leads the way in implementing and optimizing PTP in SONiC, delivering top performance on our AsterNOS Enterprise Distribution. Currently, it supports PTP Class C with a maximum time error of ≤10 ns. →For More←

Network Packet Broker Functionality (Optional)

The SONiC-based campus switches CX-M series take full advantage of SONiC’s open and containerized architecture, and fully leverage its capabilities by installing the new APP-PB container and deploying packet broker docker functionality on SONiC. This integration unlocks a range of advanced features, including traffic mirroring, raw data tagging, filtering, aggregation, preprocessing, load balancing, and output replication. →For more←

Warranty

This model is backed by a 2 year limited hardware warranty. Multiple extended support options, including advanced replacement and 24×7 support services, are available. Contact us for complete details.
